In the construction and infrastructure industries, efficiency, quality, and flexibility are paramount, and Beomach’s Mobile Batching Plants have consistently delivered on these fronts. The BEO series, equipped with state-of-the-art features such as a concrete transfer conveyor, planetary mixer, and a single shaft mixer, is designed to optimize operations for projects of varying scales.
Unrivaled Efficiency: The Mobile Batching Plant’s standout feature is the planetary mixer, renowned for its fast and uniform mixing abilities. This mixer’s unique design ensures a homogenous mix in a short time, making it ideal for high-strength concrete and specialized mix designs. Its efficient mechanism minimizes wear and tear, significantly reducing maintenance costs.
Complementing the planetary mixer, the BEO series also includes a flexible single shaft mixer capable of handling various types of concrete and materials. Its dynamic mixing action guarantees a consistent and high-quality mix every time.
Seamless Concrete Transfer: Central to the BEO series’ high productivity is the integral concrete transfer conveyor system. This system efficiently moves the prepared concrete mix from the mixer to the delivery point, minimizing waste and ensuring the mix reaches its destination in prime condition. The conveyor system improves efficiency, accuracy, and safety by reducing the need for manual handling.
Full Automation for Optimal Efficiency: Designed for the modern age, the BEO series boasts full automation. Automated control systems allow operators to manage and monitor the entire production process accurately and efficiently. From batching and mixing to transfer and dispatch, every aspect can be controlled at the touch of a button, reducing errors and downtime.
Compact and Portable Design: The BEO series’ significant advantage lies in its portability. The meticulously designed structure allows the entire plant to be shipped in a single 40-feet container. This compact design facilitates easy transportation, quick setup, and teardown, making it ideal for projects with tight schedules and limited space.
Fully Equipped for Maximum Performance: Despite its compact design, the BEO series comes fully equipped with all necessary components. From mixers and conveyors to control systems and storage units, the plant includes everything needed to promptly start producing high-quality concrete.
Conclusion: The Beomach BEO Series Mobile Batching Plant is an all-in-one solution for concrete production, setting new industry standards. Its advanced features, comprehensive equipment set, and commitment to addressing modern construction challenges make it a reliable choice for projects demanding quality, efficiency, flexibility, and portability.
| Model | BEO-30 ON-SITE CONCRETE PLANT |
|---|---|
| Plant Type | Concrete Plant With Planetary Mixer |
| Plant Capacity | Fresh Concrete 30 m³/hour |
| Aggregate Bunker Capacity | 4 x 6= 24 m³ |
| Cement Weight Capacity | 300 kg |
| Water Weight Capacity | 150 lt |
| Mixer Capacity | 750-500 lt Planetary Mixer |
| Total Engine Power | 65 kW |
| Number of Mixer Engines | 18.5 kW |
| Voltage | 380 V - 50 Hz |
| Aggregate Bunker | 4 x 6 m³ or 2 x 12 m³ Seperation Available |
| Aggregate Transfer Conveyor | 650 mm x 2450 mm |
| Cement Weighing Bunker | 300 kg |
| Water Weighing Bunker | 200 lt (Galvanized) |
| Additive Weighing Bunker | 50 lt (Galvanized) |
| Model | BEO-45 ON-SITE CONCRETE PLANT |
|---|---|
| Plant Type | Concrete Plant With Planetary Mixer |
| Plant Capacity | Fresh Concrete 30 m³/hour |
| Aggregate Bunker Capacity | 4 x 6= 24 m³ |
| Cement Weight Capacity | 400 kg |
| Water Weight Capacity | 150 lt |
| Mixer Capacity | 1250-750 lt Planetary Mixer |
| Total Engine Power | 75 kW |
| Number of Mixer Engines | 30 kW |
| Voltage | 380 V - 50 Hz |
| Aggregate Bunker | 4 x 6 m³ or 2 x 12 m³ Seperation Available |
| Aggregate Transfer Conveyor | 650 mm x 2450 mm |
| Cement Weighing Bunker | 400 kg |
| Water Weighing Bunker | 150 lt (Galvanized) |
| Additive Weighing Bunker | 50 lt (Galvanized) |
